L-SHAPED ALUMINIUM PRIVACY SCREENS

Custom Made to Your Exact Size • DIY Assembly • 7 Powder Coated Colours

Hide Outdoor Equipment With a Clean Modern Finish

Our custom-made L-Shaped Aluminium Privacy Screens are designed to neatly hide outdoor equipment while giving your home a clean, modern architectural finish.

Every screen is manufactured to your exact dimensions and supplied as an easy-to-assemble DIY kit. Simply tell us your required short side, long side and height and we will precision cut every component ready for assembly.

These versatile screens are ideal wherever you want to hide outdoor equipment while maintaining airflow and achieving a clean, modern appearance.

Perfect For

• Air conditioning screens
• Gas bottle screens
• Pool equipment screens
• Heat pump screens
• Hot water system screens
• Bin storage screens
• Utility equipment screens
• Water tank screening
• General outdoor equipment screening

These L-shaped screens use 50x50mm posts, making them a medium-duty screen option. As a general guide, they are usually best suited to sizes smaller than 800mm x 1800mm x 1400mm high.

If you want to stay with 50x50mm posts for a larger setup, we recommend a standard fully framed 3-sided enclosure instead. If you need a stronger post option, ask us about upgrading to 76x76mm posts.

Price Guide

Example price guide:

An L-Shaped Screen that is 600mm deep off the wall x 1600mm wide x 1200mm high, made with 16mm slat gaps, would be approximately:

$682

This works out to around $294 per square metre as a guide price.

Final pricing depends on your exact sizes, colour, slat gap and any upgrade options required.

Heavy Duty Aluminium Construction

Unlike lightweight decorative screens, our systems are manufactured using our premium aluminium slat system.

• Heavy Duty 100mm High x 16mm Thick aluminium slats
• 65mm and 40mm slat upgrade options available on request
• Internal dual reinforcing ribs inside every slat
• Premium powder coated finish
• No painting required, as the aluminium is powder coated with a 10-year warranty
• Designed to provide well over a decade of low-maintenance performance
• Rust-free aluminium construction

Unique Hidden F-Channel System

One feature that separates our screens from many others is our exclusive F-Channel connection system.

Rather than screwing every slat directly into the posts, each slat slides neatly into our proprietary interlocking aluminium F-Channels, which connect securely to the 50x50mm posts.

The F-Channels cover the ends of the slats, hide the fixings and help brace the screen walls for a cleaner, stronger finish.

• No visible screws through the slats
• Clean covered slat ends
• Exceptional panel strength
• Hidden fixing system
• Professional premium finish
• Simple DIY assembly

What's Included?

• Two aluminium screen walls
• Three 50x50mm aluminium corner posts
• Three internal aluminium post bases that slide neatly inside the posts
• Plastic push-in post caps
• Hidden F-Channels to cover the slat ends and hide the screws
• All alloy-to-alloy fasteners
• Complete DIY assembly kit

Simply bolt the supplied post bases to your concrete slab, slide the posts over the bases, install the F-Channels and slide the slats into position.

All you need at home is a Tek screw drill, tape measure, spirit level and a little time.

Custom Made To Your Size

Simply send us:

• Long side measurement
• Short side measurement
• Required height
• Your preferred colour
• Your preferred slat spacing

Important: We manufacture the screen to your external finished dimensions. Each wall is approximately 50mm thick, so please allow for this when calculating your final overall size.

Because every height is custom made, your chosen height may not divide perfectly by the slat spacing. This can leave a different gap at the bottom. If this is important for your application, simply ask us and we will let you know exactly what the bottom gap will be before manufacturing.

Choose Your Slat Spacing

• 0mm - fully private
• 10mm
• 16mm
• 40mm

Choose the appearance and airflow that best suits your project.

Available Colours

• Black
• White
• Paperbark Cream
• Light Grey
• Dark Grey
• Deep Ocean Blue
• Merbau Woodgrain

All colours are premium powder coated for long-lasting durability.

Need Doors?

Our 2-sided L-Shaped Screens are open-access privacy screens and cannot have doors fitted.

If you require doors or lockable access, please ask us about our 3-sided enclosures with gates instead.

• 3-sided enclosures
• 3-sided enclosures with gates
• Pool equipment enclosures
• Solar battery enclosures
• Bin enclosures
• Heat pump enclosures
• Custom utility enclosures

Fast Manufacturing

We cut customer orders every Tuesday and Thursday.

To be included in the next production run, simply place your order and pay the $250 deposit before the cut-off day.

Every component is precision cut to size before leaving our workshop.

Small Family-Run Brisbane Business

We're a small family-run Brisbane business that genuinely cuts every job in 2 working days. We don't employ salespeople or work on inflated pricing. Our pricing algorithm provides fair, transparent pricing while allowing us to manufacture quickly and consistently.

We don't leave customers waiting for weeks wondering what's happening. We process every production run and keep things moving.

Need a Quote?

SMS John your:

Long side size
Short side size
Height
Colour
Slat gap

SMS: 0414 237 573

Please Note: We manufacture custom DIY kits only. We do not provide site measuring or installation services.
